Hose & Pipe Assemblies

Hydraulic Hose Assembly

✓100% Hydrostatic Proof Tested

🛡️ Manufacturing Quality Backing

✓Mill Test Certificate (EN 10204 3.1) available

✓Hydrostatic proof tested to 2x - 4x burst safety margin

✓ISPM-15 export-compliant seaworthy crating

Technical Specifications & Standards Matrix

Standard engineering parameters. Custom sizing, specialized port threads, and bespoke geometries fabricated upon request.

Specification Parameter	Engineering Value / Rating
Length Tolerance	± 2mm (Conforming to DIN 20066)
Proof Pressure Test	2x Working Pressure on 100% of custom batches
Fittings Metallurgy	Forged Carbon Steel AISI 1215 / 316 Stainless Steel
Surface Coating	Zinc-Nickel plating exceeding 720h salt spray resistance

Engineering Overview & Design Architecture

Custom-fabricated fluid delivery solutions built to exact OEM blueprint drawings and length tolerances. Complete with protective spiral guards, heat sleeves, or fire jackets where requested.

⚡ Key Engineering Features

✓

Full Traceability: Engraved ferrule collars showing part number, pressure rating, and manufacturing date.

✓

Cleanliness Guarantee: Projectiles flushed and end-capped with plastic sealing plugs prior to packing.

🏭 Target Industry Applications

•OEM Machinery Production Lines

•Fleet Maintenance & Overhaul Centers

•Custom Hydraulic Power Pack Builds

Need customized application sizing? Our design engineers calculate hydraulic line velocities, impulse factors, and temperature drop margins to recommend exact wall thickness and crimp specs.

⚡Fast Commercial RFQ Desk
